Stainless Steel 2PC Ball Valves
This design ball valve consists of two separate pieces and one is the valve body, the other is a bonnet(cap). These data of 2PC Ball Valve is our middleweight, we both have heavier and lighter weight for different clients and market requirements.
Additional information
| Item NO | LT-52A |
|---|---|
| Size | 1/4" to 4" |
| Type of Port | Full Bore |
| Pressure | 1000WOG(PSI) |
| Material | SS304/SS316 |
| Connection | Female Thread(BSPT,BSP,NPT etc) |
Product Details
This design ball valve consists of two separate pieces and one is the valve body, the other is a bonnet(cap).
Advantage:
1. The 2-piece ball valve is relatively more resistant to high pressure between the same quality ball valves.
2. When the valves leaks, it could be repaired by changing the sealing or packing.
Disadvantage: The valve needs to be removed from the pipeline and connections only in thread or flanges when replacing parts.
These data of 2PC Ball Valve is our middleweight, we both have heavier and lighter weight for different clients and market requirements.
Our 2PC Ball Valves with many different connections:
- Female to Female thread
- Male to Female Thread
- Male to Male Thread (New)
- Male to Elbow Thread (New)
- Female to Male Adapter (New)
- Size: 1/4″ to 4″ (DN8 to DN100)
- Max Pressure: 1000WOG
- Full Bore
- Material: CF8/CF8M(SS304/SS316)
- End Connection: Female Thread-BS21(BSPT &BSP), ANSI B2.1 (NPT) etc.
- Investment Casting Body
- Blow-out Proof Stem
- Operation: Lever Handle
- OEM is acceptable and manufacturers special requirements according to your drawings.
| Size | d | L | H | W |
|---|---|---|---|---|
| 1/4″ | 10 | 55 | 46 | 91 |
| 3/8″ | 12 | 55 | 46 | 91 |
| 1/2″ | 15 | 58 | 56 | 105 |
| 3/4″ | 20 | 66 | 58 | 110 |
| 1″ | 25 | 75 | 67 | 114 |
| 11/4″ | 32 | 82 | 76 | 125 |
| 11/2″ | 38 | 93.5 | 82 | 155 |
| 2″ | 50 | 110 | 92 | 156 |
| 21/2″ | 65 | 139 | 119 | 212 |
| 3″ | 80 | 167 | 133 | 214 |
| 4″ | 100 | 202 | 162 | 312 |
| NO | Parts Name | Material |
|---|---|---|
| 1 | Body | CF8/CF8M |
| 2 | Seat | PTFE/RPTFE |
| 3 | Ball | F304/F316 |
| 4 | Gasket | PTFE |
| 5 | Cap | CF8/CF8M |
| 6 | Stem | SS304/SS316 |
| 7 | Washer | PTFE |
| 8 | Packing | PTFE |
| 9 | Gland Nut | SS304 |
| 10 | Handle | SS201/SS304 |
| 11 | Nut | A2-70 |
