Stainless Steel 1PC Ball Valve

This design thread ball valves have body and end connections formed from a single piece of material.

Additional information

Item NO	LT-51A
Size	1/4" to 4"
Type of Port	Reduced Bore
Pressure	1000WOG(PSI)
Material	SS304/SS316
Connection	Female Thread(BSPT,BSP,NPT etc)

Stainless Steel 1PC Ball Valve with Thread Ends

This design thread ball valves have body and end connections formed from a single piece of material.

Handles’ sheath can be customized according to the customer’s requirements for free, such as the color, plus the customer’s logo, etc.

Size: 1/4″ to 4″ (DN8 to DN100)
Max Pressure: 1000WOG
Material: CF8/CF8M(SS304/SS316)
End Connection: Female Thread-BS21(BSPT &BSP), ANSI B2.1 (NPT) etc.
Investment Casting Body
Blow-out Proof Stem
Operation: Manual (Lock Lever Handle & Butterfly Wing Handle Available)
OEM is acceptable and manufacturers special requirements according to your drawings.
