1PC SS Ball Valve with Butterfly Wing Handle

These design thread ball valves are usually used in space-limited places. It with a small size of 1/4″ to 1″, so do the mini ball valves.

Additional information

Item NO	LT-51B
Size	1/4" to 1"
Type of Port	Reduced Bore
Pressure	1000WOG(PSI)
Material	SS304/SS316
Connection	Female Thread(BSPT,BSP,NPT etc)

Stainless Steel 304/316 SS Ball Valve with Butterfly Wing Handle

These design thread ball valves are usually used in space-limited places. It with a small size of 1/4″ to 1″, so do the mini ball valves.

Size: 1/4″ to 1″ (DN8 to DN25)
Max Pressure: 1000WOG
Reduced Bore
Material: CF8/CF8M(SS304/SS316)
End Connection: Female Thread-BS21(BSPT &BSP), ANSI B2.1 (NPT) etc.
Investment Casting Body
Blow-out Proof Stem
Operation: Butterfly Wing Handle
OEM is acceptable and manufacturers special requirements according to your drawings.
